Penetration Grade Bitumen – EN Standards and Grades
Penetration grade bitumen is a cornerstone material in road construction, paving, and waterproofing projects, known for its exceptional durability and flexibility. Under the EN (European Norm) standard, bitumen is classified based on its penetration values to meet diverse climatic and structural needs. This page delves into EN-standard penetration grades such as 20/30, 30/45, 35/50, 40/60, 50/70, 70/100, 100/150, and 160/220.
What is Penetration Grade Bitumen?
Penetration grade bitumen is categorized based on its hardness or softness, determined by the penetration value (measured in tenths of a millimeter). This measurement is performed under specific conditions as per EN 1426 standards. EN-standard grades are engineered for diverse applications, offering unparalleled performance under various temperatures and loads.
Grades of Penetration Bitumen Under EN Standards
Below is a comprehensive overview of penetration-grade bitumen under EN standards:
| Grade | Penetration (mm) | Softening Point (°C) | Application |
|---|---|---|---|
| 20/30 | 20 to 30 | High | Heavy-duty roads in hot climates. |
| 30/45 | 30 to 45 | Medium | Industrial areas and high-load pavements. |
| 35/50 | 35 to 50 | Medium | High-traffic urban roads. |
| 40/60 | 40 to 60 | Moderate | General road construction. |
| 50/70 | 50 to 70 | Moderate | Highways and medium-traffic pavements. |
| 70/100 | 70 to 100 | Medium | Low-traffic pavements and maintenance. |
| 100/150 | 100 to 150 | Low | Flexible pavements in colder climates. |
| 160/220 | 160 to 220 | Very Low | Temporary and low-load roads. |
Key Features of Penetration Grade Bitumen
Penetration Value
- Indicates bitumen’s consistency and suitability for specific climates and applications.
Softening Point
- Represents the temperature resistance of bitumen, crucial for projects in extreme weather.
Viscosity
- Ensures consistent flow and stability during application.
Bitumen Packing Methods
To accommodate various project needs, penetration-grade bitumen is packed in different formats. These packing methods ensure safe transportation and convenient handling:
Steel Drums
- Capacity: 150 kg ,180 kg & 200kg
- Benefits: Easy to transport and store.
Bulk Tankers
- Delivered in heated tankers.
- Benefits: Ideal for large-scale projects, reducing waste.
Jumbo Bags
- Capacity: 40 Kg ,300 Kg &1 ton.
- Benefits: Cost-effective for bulk requirements.
Polyethylene Bags
- Compact and eco-friendly.
- Benefits: Reduces spillage and ensures precise quantities.
Specification Sheet for EN Penetration Grade Bitumen
Here is a sample specification sheet for EN-standard penetration grade bitumen 50/70:
| Property | Unit | Test Method | Specification |
|---|---|---|---|
| Penetration | mm | EN 1426 | 50 to 70 |
| Softening Point | °C | EN 1427 | 46 to 54 |
| Flash Point | °C | EN ISO 2592 | Min 230 |
| Specific Gravity | - | EN ISO 3675 | 1.01 to 1.06 |
| Solubility in TCE | % | EN 12592 | Min 99.5 |
| Loss on Heating | % | EN 12607-1 | Max 0.5 |
Quality Standards of Penetration Grade Bitumen
EN standards ensure that penetration-grade bitumen meets stringent quality benchmarks:
Consistency
- Each grade is rigorously tested for uniform penetration and viscosity values.
Durability
- Engineered to resist aging and environmental degradation.
Safety
- Flashpoint tests ensure safe handling and application during use.
Eco-Compliance
- Meets environmental guidelines for sustainable infrastructure development.
Applications of Penetration Grade Bitumen
Penetration-grade bitumen is highly versatile and suitable for a variety of construction and industrial uses:
Road Construction
- Acts as a reliable binder in asphalt mixes.
- Increases the durability of pavements.
Maintenance and Repairs:
- Ideal for pothole filling and surface treatments.
Waterproofing:
- Used in roofing and bridge deck waterproofing.
Industrial Products
- Key ingredient in adhesives, sealants, and insulation materials.
Why Choose EN-Standard Penetration Bitumen?
Performance
- Designed to withstand diverse environmental conditions.
Versatility
- Suitable for a wide range of climates and applications.
Reliability
- Ensures long-lasting results and reduced maintenance costs.
Global Recognition
- Trusted and certified under European Norm standards.
Interested in purchasing high-quality cutback bitumen for your construction or industrial project? Contact us today for more information on the grades, applications, and packaging options available. Fill out the form below to request a custom quote, and our team will respond promptly.
